🐾AppSync for GraphQL: When it actually shines🐾

🤓 “AppSync is for GraphQL” seems like obvious advice. Yet I keep seeing teams either implement GraphQL on API Gateway + Lambda, or worse — regret their AppSync choice six months in.

The typical framing is: “Do you need GraphQL? Use AppSync.” But the actual question should be: “What are you optimizing for, and what operational complexity can your team handle?” Let me show you where AppSync genuinely excels — and the hidden costs.

✅ When AppSync shines: Real-time subscriptions

AppSync subscriptions are transformative for real-time updates. They handle WebSocket connections, message filtering, and fan-out automatically.

type Subscription {
  onOrderStatusChange(customerId: ID!): Order
    @aws_subscribe(mutations: [”updateOrderStatus”])
}

With API Gateway, you’d build this yourself: WebSocket APIs + DynamoDB connection tracking + Lambda broadcasting. That’s 3-4 services vs AppSync’s built-in handling.

The cost reality: WebSocket connections cost money even when idle.

For 10,000 users connected 8 hours/day (rough estimate):

• Connections: $0.08/million minutes = ~$384/day

• Messages: $1.00/million messages

If your “real-time” is actually “poll every 30 seconds,” REST might be cheaper.

✅ When AppSync shines: Multi-source data federation

One GraphQL query, multiple data sources in parallel:

type User {
  profile: UserProfile      # DynamoDB
  orders: [Order]           # RDS Aurora
  recommendations: [Product] # Lambda + ML
}

AppSync orchestrates this automatically. With API Gateway + Lambda, you write the orchestration logic yourself.

The N+1 problem: Watch out for this query:

{
  users(limit: 100) {
    orders  # 100 separate DB calls!
  }
}

AppSync makes 1 call for users, then 100 calls for orders. You need DataLoader patterns or batch resolvers to fix this.

✅ When AppSync shines: Schema-first discipline

AppSync forces you to maintain a .graphql schema file as your API contract:

• Frontend teams work from schema immediately

• Breaking changes are explicit

• Auto-generated documentation via GraphiQL

• Prevents “nobody knows what the API actually does” syndrome

This is less about AppSync features and more about enforced discipline that pays off.

✅ When AppSync shines: Field-level authorization

AppSync’s authorization is underrated. You get four modes (API Key, IAM, Cognito, OIDC) that can be applied per-field:

type User {
  id: ID!
  email: String @aws_auth(cognito_groups: [”Users”])
  salary: Float @aws_auth(cognito_groups: [”Admins”])
}

Same type, different field-level permissions. With API Gateway, you’d implement this in every Lambda resolver manually. AppSync supports multiple auth modes per API natively. Some fields use Cognito, others use IAM, others use API keys — all in one schema.

The limitation: Authorization is tied to Cognito groups or IAM policies. Custom RBAC (permissions stored in your DB) still needs Lambda resolver logic.

⛔ When AppSync disappoints: The VTL reality

AppSync promises “no Lambda needed” via VTL (Velocity Template Language) resolvers:

{
  “version”: “2017-02-28”,
  “operation”: “Query”,
  “query”: {
    “expression”: “PK = :pk”,
    “expressionValues”: {
      “:pk”: $util.dynamodb.toDynamoDBJson($ctx.args.userId)
    }
  }
}

This works for simple CRUD. But add:

• Business logic (discounts, access control)

• External API calls with retries

• Complex data transformations

• Any if/else beyond basics

You’re writing Lambda anyway. Now you maintain VTL templates AND Lambda code.

Reality check: In every production AppSync API I’ve observed, 60%+ of resolvers use Lambda. The “no Lambda” promise rarely survives contact with real requirements.

Update (late 2022): AWS introduced APPSYNC_JS runtime as a VTL replacement. You can now write resolvers in JavaScript. It’s still not full Node.js. No npm packages, limited standard library. Async/await works for AppSync operations, but external HTTP calls need Lambda anyway. For complex business logic, you’re still reaching for Lambda. But for data access patterns, APPSYNC_JS is a significant improvement over VTL.

🎁Production gotchas:

• Pipeline resolvers: use these to chain multiple logic steps (e.g., Auth → Validation → DB call) without repeating code. They turn fragmented VTL/JS into a reusable sequence. Powerful but under-documented.

• HTTP resolvers: allow AppSync to act as a GraphQL Gateway. You can proxy existing REST or even external GraphQL APIs directly, merging legacy services into your new graph.

• Caching: AppSync now offers two layers. Resolver-level caching is the default (5 resolvers check cache 5 times), but Operation-level caching (new in 2025) finally allows you to cache the entire query response natively.

• 256KB request limit: a hard limit for the total request (payload + headers). While API Gateway handles 10MB, AppSync requires you to offload large data or file uploads to S3 using pre-signed URLs.

• VTL has no debugger: Unlike API Gateway, there is no true local runtime. You can use basic simulators like Amplify Mock, but for complex logic, you are stuck with $util.log() and CloudWatch. Local testing remains the biggest developer experience bottleneck.

---
